Shubhangi Shitole

• With 7+ years of professional experience, including 4+ years of experience in PCB design.
• Proficient in multilayer, high power, high speed and RF PCB design.
• Domain : Automotive, Lighting systems, Health Care, Instrumentation Systems.
• Protocols: CAN, Ethernet, I2C, RS485, SPI, and USB etc.
• Tools : Altium 24.4, Orcad Allegro 17.4, Mentor Graphics PAD 4.

Project 1: Transducer Board for Bullet Train

Synopsis : Designed transducer board to implement in Bullet train which includes pressure sensors, flow sensors and barometer incorporated in it. Pressure sensors are operated using switch and resistance between switch contacts are adjusted using butterworth filter.

Protocol : I2C

Tool : Altium

Standard : IPC

Project 2: Electric Thermostat

Synopsis : Electric Thermostat is designed to maintain temperature of boilers using NTC thermister.

Protocol : RS485

Tool : Altium

Standard : IPC, UL.

Project 3: IO Board

Synopsis : High speed board designed for communication with parent blackbelt board.

Protocol : CAN, Ethernet, USB, LVDS, SPI and RS485.

Tool : Altium

Standard : IPC.

Project 4: Water Flow Meter

Synopsis : Domestic water meter is used to measure total water uses and RF is used for transmitting readings over RF using LoRa, Bluetooth

Protocol : Bluetooth BM70/BM71

Tool : Altium

Standard : IPC.

Project 5: LED Driver

Synopsis : Designed LED PCB drivers for 2wheeler & 4 wheeler head lights considering mechanical constraints. Driver IC placement, routing is done by considering EMI/EMC compliance.

Tool : Altium

Standard : IPC.
