Summary

  • Experience in block-level Physical Design - RTL to GDSII
  • Experience in Static Timing Analysis and Timing Closure
  • Experience in Physical verification - DRC/LVS, IR/EM, ECO cycle
  • Experience in Full chip clock planning, FCT & FCFP
  • Experience in Power FSDB's & SAIF
  • Experience in TCL, Bash, Perl & Python scripting and automation
  • Experience of working in 28nm, 32nm, 7nm & 5nm technology nodes

Overview

9
9
years of professional experience

Work History

Lead Physical Design Engineer

Signoff Semiconductors Pvt. Ltd.
02.2019 - Current
  • Responsible for FSDB validation & integration to tile PNR for power optimization as power lead.
  • Annotations, mappings & validation with automated scripts written for this project.
  • Validating power intent and activity data consistency across simulation and synthesis stages to ensure power-aware design integrity.
  • Helping Hyderabad PNR team on any PNR & flow Issues.
  • Handling 2 resources for two parallel projects.
  • 1 resource is new to clock gave complete KT on full chip clock activities.
  • Logical connections planning for all clocks.
  • Pushdown planning, Custom routing, Tmac simulations, Skew fixing & Automation.

Lead Physical Design Engineer

Signoff Semiconductors Pvt. Ltd.
01.2024 - 10.2025
  • Responsible for handling 10 tiles (4 critical, 3 medium, 3 repeater tiles & PLL 2 blocks).
  • PNR - responsible for PPA metrics closure across all milestones (LSA-LSD final PNR).
  • Floorplan reviews, qor reviews across all stages & feedback to Tile owners.
  • Eco execution and convergence on time.
  • In sync with all stakeholders in issues resolving- RTL, FCFP, FCT, Constraints & flow teams.
  • Worked in A0 & B0 versions of projects.
  • Supported other chips in chiplet for PV closure with team of 10 members for on time BTO & MTO delivery.
  • Executed all post project executions - final jiras, post tapeout issues validation, Disk reclaim & Backups for 60 tiles in project.
  • Responsible for mentoring new engineers.

Lead Physical Design Engineer,Clock Engineer

Signoff Semiconductors Pvt. Ltd.
10.2022 - 12.2024
  • Clock pushdown planning & review.
  • Logical connections for all clocks.
  • Tile level feedback implementations on pushdown cells.
  • Skew, latency, uncertainty iterations & simulations.
  • Manual DRC/EM/IR aware RDL routing with shielding's with Balanced net lengths.
  • CES simulations for GC_GFXCLK skew, latency, tran, cap, fanout fixing and balancing across 20 levels.
  • Guiding and supporting Hyderabad team juniors in AMD PNR flow, DTCO trails, ECO flows and support.
  • Responsible for mentoring new engineers.

Senior Physical Design Engineer

Signoff Semiconductors Pvt. Ltd.
04.2022 - 08.2022
  • Responsible for handling a block in Eco cycle.
  • Responsible for lead Role with the team of 8 blocks.
  • Worked on generating timing Eco's both manually and by scripting to implement it in the design.
  • Converged a complex timing and routing critical design.
  • Responsible for mentoring new engineers.

Physical Design Engineer

Signoff Semiconductors Pvt. Ltd.
03.2019 - 10.2019
  • Responsible for ECO, Timing Closure and Physical Verification and IR/EM fixes for multiple tiles.
  • Static timing analysis and Timing closure. DRC/ LVS fixing.

Associate Consultant

CapGemini Pvt. Ltd.
09.2016 - 02.2019
  • Development and unit testing of Problem Report, Change Request and Enhancement Request.
  • Created and documented conceptual and detail design of the application based on a description of the software requirement and specifications.
  • Coordinated with Solution Architects for any design change in application or any patch fix.
  • Responsible for IKEA OMS (Order Management System) & VMI (Vendor Managed Replenishment) Backend coding & operations.
  • Coding of PL/SQL procedures, functions, and code reviews & checkins.
  • Fully involved in the SDLC, used agile mode for the development.
  • Automating the Routine tasks in Automation Anywhere and integration.

Education

SSC - undefined

Z.P.H.School
01.2010

Intermediate - undefined

Sri Chaitanya jr. college
01.2012

B.Tech - Electronics and Communications Engineering

KITS Markapur
01.2016

Skills

  • VLSI Physical Design
  • PnR flow
  • Floorplanning
  • Placement
  • CTS
  • Routing
  • Synthesis
  • ECO flow
  • Static Timing Analysis
  • Timing Closure
  • DRC fixing
  • Secondary metrics fixing
  • Full Chip Clock planning
  • Simulations
  • Physical Verification
  • Power optimization
  • AI
  • PD Agent
  • GENIE
  • PD GURU
  • Advance prompting
  • Entry level AI Generalist
  • TCL
  • Python
  • Verilog
  • Perl
  • Automation
  • IC Compiler II
  • Fusion Compiler
  • Innvos
  • OpenRoad
  • StarRC
  • Verdi
  • Prime Time
  • Prime Closure
  • Calibre
  • TSMC 28nm
  • TSMC 32nm
  • TSMC 7nm
  • TSMC 5nm
  • TSMC 2nm

Languages

TCL
Python
Verilog
Perl
Automation

Personal Information

  • Total Experience: 9 years
  • Title: Lead Physical Design Engineer

Personal Qualifications

B.Tech, Electronics and Communications Engineering, JNTUK University

Primary Skills

  • 7+ years experience in VLSI Physical Design
  • PnR flow - Floorplanning, Placement, CTS, Routing
  • Synthesis
  • ECO flow - Static Timing Analysis, Timing Closure, complex DRC & Secondary metrics fixing
  • Full Chip Clock planning & Simulations
  • Physical Verification
  • Power optimization FSDB, SAIF
  • AI enthusiast, PD Agent, GENIE, PD GURU, Advance prompting, Entry level AI Generalist

Eda Tools

IC Compiler II, Fusion Compiler, Innovus, OpenRoad, StarRC, Verdi, Prime Time, Prime Closure, Calibre

Tech Nodes Experience

  • TSMC 28nm
  • TSMC 32nm
  • TSMC 7nm
  • TSMC 5nm
  • TSMC 2nm
